Frame
Spark Carbon HMF
Integrated Suspension Technology
Flex Pivot / Adjustable head angle
Syncros Cable Integration System
BB92 / UDH Interface / 12x148mm with 55mm Chainline
Fork
FOX 34 Float Performance Elite Air FIT4
3-Modes with low Speed adj. / Kabolt 15x110mm axle
44mm offset / tapered steerer / Reb. Adj. / Lockout
130mm travel
Rear Shock
FOX NUDE 5T EVOL Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Custom large Air volume / DPS / Reb. Adj.
Travel 120-80-Lockout / T165X45mm
Remote System
SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes

Rear Derailleur
Shimano XT RD-M8100 SGS
Shadow Plus / 12 Speed
Shifters
Shimano XT SL-M8120-IR / Rapidfire Plus
Ispec EV clamp
Crankset
Shimano XT FC-M8120-1 / Hollowtech 2
32T
BB-Set
Shimano SM-BB71-41A / shell 41x92mm
Chain
Shimano SLX CN-M7100
Cassette
Shimano XT CS-M8100-12 / 10-51 T
Brakes
Shimano XT M8120 4 Piston Disc
Rotor
Shimano SM-RT76 / 6 Bolt / F&R 180mm
Handlebar
Syncros Fraser 1.5 DC Alloy 7075 D.B.
mini Rise / back sweep 8° / 760mm
Syncros Pro lock-on grips
H'stem
Syncros DC 1.5
Syncros Cable Integration System
0° rise / 7050 Alloy / 31.8mm / 1 1/8"
Seatpost
FOX Transfer Performance Elite Dropper Post
31.6mm / S & M size 125mm / L & XL size 150mm
Seat
Syncros Tofino 1.5 Regular
Titanium rails
Headset
Syncros - Acros Angle adjust & Cable Routing HS System
+-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB
Wheelset
Syncros Silverton 2.0-30 6 Bolt
F: 15x110mm, R: 12x148mm
30mm Tubeless ready rim 28H / Micro Spline
Syncros Axle w/Removable Lever
with 6mm Allen, T30 and T25 Tools
Front Tire
Schwalbe Wicked Will 29x2.4" EVO
Super Race / TLE / 67EPI / Addix Speed Soft
Rear Tire
Schwalbe Wicked Will 29x2.4" EVO
Super Race / TLE / 67EPI / Addix Speed Grip
Approx weights in KG
12.3 (Tubless setup)
Approx weights in LBS
27.12 (Tubless setup)
Max. System Weight
128 kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
