Cadre
Lumen eRIDE Carbon HMX
Integrated Suspension Technology
Flex Pivot / Adjustable head angle
Syncros Cable Integration System
TQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline
Débattement
Front: 130mm / Rear: 130mm
Fourche
FOX 34 Float Rhythm Air Grip
3-Modes / Kabolt 15x110mm axle / tapered steerer
44mm offset / Reb. Adj. / Lockout / 130mm travel
Amortisseur arrière
FOX NUDE 5T EVOL Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Custom large Air volume / DPS / Reb. Adj.
Travel 130-90-Lockout / T165X45mm

Levier de contrôle
SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes
Moteur
TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph
Batterie
TQ Internal 360Wh
Ecran
TQ HPR
Bluetooth / ANT+ / Dedicated Smartphone app
Chargeur
TQ 100-240V-4A
Dérailleur arrière
Shimano XT RD-M8100 SGS
Shadow Plus / 12 Speed
Manettes de dérailleur
Shimano Deore SL-M6100-IR / Rapidfire Plus
Ispec EV clamp
Pédalier
FSA Alloy crankset / 175mm / 34T
Guide-chaîne
e*thirteen / e*spec Slider
Plateau
Scott custom spider / FSA 12Speed 34T chainring
Chaîne
Shimano CN-M6100
Cassette
Shimano CS-M6100 / 10-51 T
Freins
Shimano Deore M6120 4 Piston Disc
Disque de frein
Front: SM-RT64 CL 180mm / Rear: RT-EM600 CL 180mm
Cintre
Syncros Fraser 2.0 DC Alloy 6061 D.B.
mini Rise / back sweep 8° / 760mm
Syncros Performance XC lock-on grips
Potence
Syncros DC 2.0
Syncros Cable Integration System
0° rise / 6061 Alloy / 31.8mm / 1 1/8"
Tige de selle
Syncros Duncan Dropper Post 2.0
31.6mm / S & M size 125mm / L size 150mm
Selle
Syncros Savona 1.5 V-Concept
Jeu de direction
Syncros - Acros Angle adjust & Cable Routing HS System
+-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB
Moyeu avant
Formula CL-811 / 15x110mm
Moyeau arrière
Formula CL-148M / 12x148mm / Micro Spline
Syncros Axle w/Removable Lever
with 6mm Allen, T30 and T25 Tools
Rayons
Stainless Black 15G / 1.8mm
Jante
Syncros X-30SE / 32H / 30mm
Tubeless ready
Pneu avant
Schwalbe Wicked Will 29x2.4" EVO
Super Race / TLE / 67EPI / Addix Speed Soft
Pneu arrière
Schwalbe Wicked Will 29x2.4" EVO
Super Race / TLE / 67EPI / Addix Speed Grip
Poids en Kg (App.)
17.6 (Tubeless setup)
Poids en Lbs (App.)
38.8 (Tubeless setup)
Poids global
128kg
Le poids total comprend le vélo, le pilote, l’équipement et les bagages supplémentaires.
